White magic

This system has been built and tuned for the ultimate in experience in low-latency, high-refresh rate gaming and streaming. At the heart is the Ryzen 7 5800X, my favorite chip out of the new Zen 3 CPU lineup for its delivery of eight cores and sixteen threads on a binned, single-ccx, single-ccd CPU design. The main drawback of Ryzen has always been the latency inherent to its multi-ccx chip design, with this CPU being the first Ryzen 7 to have all its cores on a single die, reducing the problematic impact of core-switching between two dies and slower access to the chip's L3 cache. While the Ryzen 9 may have more cores, its multi-ccx construction means this R7 is the Zen 3 chip you want if you're after peak responsiveness in games.

Complimenting this CPU is 32GB of G-Skill Ripjaws V DDR4 clocked at 3600MHz, further reducing system latency by accelerating the infinity fabric connection the CPU has to the rest of the system. A sizable boot NVME SSD further boosts system responsiveness, with a sprightly SATA SSD providing any additional storage you may need.

And finally, the graphics card is what's in my opinion the most beautiful 30-series card ever manufactured-- the Gigabyte VISION RTX 3070 OC. It's also one of the best performing custom 3070's, featuring enhanced power delivery, a flow-through cooler design, and of course, a factory overclock. It's a stellar performer in high-settings 1440p, 1080p, and DLSS-enabled 4k gaming.

Find the full specs and benchmarks below.

Specifications: https://pcpartpicker.com/list/svg4j2
GPU- Nvidia RTX 3070 GIGABYTE VISION OC (w/ 8GB GDDR6)
CPU- AMD Ryzen 7 5800X (8 Cores, 16 Threads @ up to 4.9GHz)
RAM- 32GB G.Skill Ripjaws V DDR4 in Dual Channel @3600MHz (18-22-22-44-CR1)
NVME SSD- 512GB NVME Inland Premium Solid State Drive
Sata SSD- 1TB Samsung 870 QVO Solid State Drive
Mobo- AsRock B550M Pro4 Micro-ATX Motherboard
PSU- 750 Watt PowerSpec Semi-Modular Power Supply (80+ Bronze Certified) w/ purple sleeved & braided cable extentions
Case- DarkFlash DLM21 Micro-ATX Mid-Tower w/ Four White AsiaHorse aRGB Fans
Cooler- 240MM ID-COOLING AURAFLOW X 240 Snow Edition AIO Liquid Cooler w/ Two aRGB White Fans
OS- Windows 10 Enterprise (latest version, activated)
Connectivity- Gigabit LAN

Benchmarks:
Userbench- https://www.userbenchmark.com/UserRun/39182330
Furmark- https://gpuscore.top/furmark/show.php?id=277315
Cinebench R15- Multicore: 2570, Single Core: 270
Cinebench R20- Multicore: 6048, Single Core: 636
Cinebench R23- Multicore: 15562, Single Core: 1626
CrystalDiskMark- 3431MB/s Read, 2429MB/s Write
Aida64 Memory Latency- 62.4 nanoseconds

The PC has been thoroughly tested to ensure excellent thermals and unwavering stability.
Color(s): White
RGB Lighting? Yes
Theme: Color
Cooling: AIO Cooling
Size: Micro-ATX
Type: General Build

Contests

This build participated in 1 contest.

Hardware

CPU
$ 181.99
AMD - Ryzen 7 (5800X)
Socket: AM4
Cores: 8
Motherboard
$ 142.99
ASRock - B550M ITX/AC
Chipset: B550
CPU Socket: AM4
Size: Mini-ITX
Memory
$ 59.99
G.Skill - Ripjaws V (3600MHz) (Black)
Type: DDR4
Capacity: 32 GB
Graphics
$ 1,100.00
Gigabyte - GeForce Vision OC
Chip Manufacturer: NVIDIA
Chip: RTX 3070
Interface: PCIe x16
Storage
$ 65.99
Inland Professional - Inland Premium
Form Factor: M.2
Interface: M.2 (M)
Capacity: 512 GB
Storage
$ 104.99
Samsung - 870 QVO
Form Factor: 2.5 Inch
Interface: SATA 6 Gb/s
Capacity: 1 TB
PSU
$ 132.02
PowerSpec - Super Power
Wattage: 850
Form Factor: ATX
Efficiency: 80+ Gold
Case
$ 68.99
DarkFlash - DLM21 Mesh (White)
Type: Micro-ATX
Side Panel: Tempered Glass
Case Fan
$ 60.00
Cooling
$ 59.49
ID-COOLING - Auraflow X (Snow)
Type: Waterblock
Size (WxHxD): 240 mm
CableMod
$ 15.00
Accessories
$ 139.99
Accessories
$ 131.99
Monitor
$ 279.00
ASUS - TUF Gaming (VG279QM)
Size: 27 Inch
Panel: IPS
Refresh Rate: 280 Hz
Monitor
$ 179.00
ASUS - VG278QR
Size: 27 Inch
Panel: TN
Refresh Rate: 165 Hz
Keyboard
$ 279.50
Corsair - K70 RGB MK.2 SE
Interface: Wired
Key Switch Type: Cherry MX Speed
Type: Full Size
Mouse
$ 97.99
Corsair - M65 Elite RGB
Interface: Wired
Chair
$ 200.00
GT Omega - Sport
Material: Hybrid Leather
Color: Black, White
Estimated total value of this build:
$ 1,955.96
