Woodilicious!

After the success I had with the previous wooden case I did, I decided to take on another project. This time I was going to design a wooden ITX case that would support a 280mm AIO. Check out the full process here: https://youtu.be/B5zZkGwnLIE

This case has some improvements from the learnings of the previous. - The magnetic mounts are now in 2 parts, with only a slim magnet glued to the glass panels. (for easier install/removal of the glass) - The wooden frame is now connected with 45° joints to create the "waterfall" grain effect - A rabbet is cut into the top panel to hide the plywood edge of the rear panel - Aesthetic 3D printed parts have been primed and painted to look more professional

DIMENSIONS:

(L x W x H) 262 x 198 x 406 mm /10.3" x 7.8" x 16"
Color(s): Brown
RGB Lighting? Yes
Theme: Retro
Cooling: AIO Cooling
Size: Mini-ITX
Type: General Build

Hardware

CPU
$ 100.65
Intel - Core i5-10400F
Socket: LGA 1200
Cores: 6
Integrated Graphics: Yes
Motherboard
$ 289.80
ASUS - ROG Strix (B460-I)
Chipset: B460
CPU Socket: LGA 1200
Size: Mini-ITX
Memory
$ 94.99
Corsair - Vengeance Pro SL (3600MHz) (Black/RGB)
Type: DDR4
Capacity: 32 GB
Graphics
$ 399.99
EVGA - GeForce FTW3
Chip Manufacturer: NVIDIA
Chip: GTX 1080 Ti
Interface: PCIe x16
Storage
$ 249.99
Sabrent - Rocket Q
Form Factor: M.2
Interface: PCIe x4
Capacity: 2 TB
PSU
$ 137.99
SilverStone Technology - SST-SX650-G
Wattage: 650
Form Factor: SFX
Efficiency: 80+ Gold
Case
Custom - Custom (custom)
Cooling
$ 95.99
ARCTIC - Liquid Freezer II
Type: AIO
Size (WxHxD): 280 mm (2 x 140 mm)
