Silent breeze

I have deshrouded the GPU. The GPU is undervolted (1874mhz, 875mv), the CPU is stock.

After some testing on fan configurations, the best way is to use bottom fans as intake and fuma fans as intake too (reversed).

The temps are as following :
CPU 100% fan speed, prime 95 small FFT 30 minutes : 34c delta
GPU 100% fan speed, superposision 1440p all maxed (GPU load 95+) : 38c delta

Of course, i don't run the system full blast, with a quiet CPU and GPU curves, temps are as following in a 24c room (2h of call of duty campaing gameplay then a game install who spiked the CPU at 100%):
CPU max 74c (temps of prime are lower because the CPU lower its voltage and clocks to stay withing reasonable TDP without spikes)
GPU max 67c

The funny thing is the GPU is quieter than the CPU and the CPU is cooled by a fuma 2.

Oh and the system works without issue with a 600w corsair platimun PSU. I even played 30 minutes of half life alyx and the headset was powered through USB without any issue.
Color(s): Black
RGB Lighting? Yes
Theme: none
Cooling: Air Cooling
Size: Mini-ITX
Type: General Build

Hardware

CPU
$ 265.00
AMD - Ryzen 7 (3700X)
Socket: AM4
Cores: 8
Motherboard
$ 348.68
Gigabyte - AORUS I Pro (WiFi)
Chipset: X570
CPU Socket: AM4
Size: Mini-ITX
Memory
$ 422.54
Crucial - Ballistix (3600MHz) (White/RGB) (2x)
Type: DDR4
Capacity: 16 GB
Graphics
$ 800.00
MSI - GeForce Ventus 3X OC
Chip Manufacturer: NVIDIA
Chip: RTX 3080
Interface: PCIe x16
Storage
$ 117.39
Corsair - Force MP300
Form Factor: M.2
Interface: M.2 (M)
Capacity: 240 GB
PSU
$ 144.99
Corsair - SF600
Wattage: 600
Form Factor: ATX
Efficiency: 80+ Platinum
Case
$ 102.99
Cooler Master - NR200P
Type: Mini-ITX
Side Panel: Mesh
Case Fan
$ 59.90
Noctua - NF-A12x15 PWM (Brown) (2x)
Size: 120 mm
Case Fan
$ 59.90
Noctua - NF-A12x25 5V PWM (2x)
Size: 120 mm
Cooling
$ 59.99
Scythe - Fuma 2
Type: Air Cooler
Size (WxHxD): 120 mm
Estimated total value of this build:
$ 2,430.72
