School PC

Hello Everyone!

I wanted to enter my pc build for a chance at receiving a prize. I want to thank builds.gg and all the sponsors for this amazing giveaway!

PC partpicker link: https://pcpartpicker.com/list/xWL6F8

Details:

This build was my first small form factor pc that I have built for my self ( I have built a few other sff pcs). The only hitch that I encountered was the cable management, but that is because I did not get custom cables for this pc. However, with the use of zipties and some time, I was able to get the cable mgmt where I wanted (no where near some of you tryhards on this subreddit lol).

Case Build Quality:

I have built in a few other sff cases like the nr200 and the sliger sm560. The sm560 and the cooler master nr200 had better quality materials in my opinion, but the M1 is no slouch in build quality. The side panels were easy to remove and the build went smoothly.

Thermals:

The thermals are great in this case though. I don't have that of a power hungry gpu in the 1070, but I think the case does a great job at expelling heat.

CPU:

Cinebench r23 multi-core (one loop): maxed out at 77 C with a more silenced fan curve

GPU:

Heaven 4.0: maxed out at 60 C with an adjusted fan curve

Final Thoughts:

I love this pc and it does everything I need it to do, while being one of the best looking pcs that I have ever built and I want to thanks all those on here who helped me get this build finished.
Color(s): Aluminum Black
RGB Lighting? No
Theme: none
Cooling: Air Cooling
Size: SFF
Type: General Build

Contests

This build participated in 1 contest.

Hardware

CPU
$ 90.99
AMD - Ryzen 5 (3600)
Socket: AM4
Cores: 6
Motherboard
$ 253.86
Gigabyte - AORUS Pro (WiFi) (B450I)
Chipset: B450
CPU Socket: AM4
Size: Mini-ITX
Memory
$ 54.99
TeamGroup - T-Force Vulcan (3200MHz) (Grey)
Type: DDR4
Capacity: 16 GB
Graphics
$ 409.00
EVGA - GeForce SC2 Gaming
Chip Manufacturer: NVIDIA
Chip: GTX 1070
Interface: PCIe x16
Storage
$ 50.99
Crucial - P2
Form Factor: M.2
Interface: M.2 (M)
Capacity: 500 GB
Storage
$ 46.72
Seagate - Barracuda (ST1000LM048)
Form Factor: 2.5 Inch
Interface: SATA 6 Gb/s
Capacity: 1 TB
PSU
$ 155.05
Corsair - SF600
Wattage: 600
Form Factor: SFX
Efficiency: 80+ Gold
Case
$ 210.00
Ncases - NCase M1
Type: Mini-Tower
Side Panel: Solid
Case Fan
$ 10.61
Case Fan
$ 10.61
Case Fan
$ 13.95
Noctua - NF-B9 redux-1600
Size: 92 mm
Cooling
$ 69.95
Noctua - NH-U9S chromax.Black
Type: Air Cooler
Size (WxHxD): 92 mm
Estimated total value of this build:
$ 1,376.72
