HydroSphere

Cooling System Summary

System Components:
CPU: AMD Ryzen 7800X3D

Waterblock:
Dimensions: 70 x 70 x 32.5 mm
Materials: Nickel-plated copper (cooling plate), Brass (bottom part), Acrylic (top part)
Threads: 2 x G1/4“
Max Working Temperature: 60°C

Radiator:
Dimensions: 391.5 x 124 x 30 mm
Material: Copper
Fin Density: 15 FPI
Threads: 2 x G1/4“
Pump:
Flow Rate: 1500 l/h
Head Pressure: 2-4 m

Fans:
Dimensions: 120 x 120 x 25.5 mm
Air Flow: 70.98 CFM
Static Pressure: 4.23 mmH2O
Noise: 40.1 dBA

Cooling Liquid:
Composition: 95% distilled water, 4.2% Glysofor L, 0.7% Rhoba Clear, 0.1% colorant

Ambient Temperature: 30°C
Performance Estimate

Water Temperature:
Delta T (temperature difference between the CPU and the water): Estimated between 5°C and 7°C.
Water Temperature:
Minimum: 30°C (ambient) + 5°C (delta T) = 35°C
Maximum: 30°C (ambient) + 7°C (delta T) = 37°C
Color(s): Black Chrome
RGB Lighting? Yes
Theme: Futuristic
Cooling: Custom Liquid Cooling
Size: Mini-ITX
Type: General Build

Hardware

CPU
$ 476.00
AMD - Ryzen 7 7800X3D
Socket: AM5
Cores: 8
Integrated Graphics: Yes
Motherboard
$ 299.00
ASUS - ROG Strix B650E-I Gaming (WiFi 6E)
Chipset: B650
CPU Socket: AM5
Size: Mini-ITX
Memory
$ 119.99
Corsair - Vengeance (6000MHz) (Black/RGB)
Type: DDR5
Capacity: 32 GB
Graphics
$ 361.19
ASUS - GeForce Dual OC
Chip Manufacturer: NVIDIA
Chip: RTX 3060
Interface: PCIe x16
Storage
$ 119.99
Samsung - 990 Pro
Form Factor: M.2
Interface: PCIe x4
Capacity: 2 TB
PSU
$ 149.99
Corsair - SF850L
Wattage: 850
Form Factor: SFX
Efficiency: 80+ Gold
Case
Hydra - Mini
Type: Mini-ITX
Side Panel: Open
Cooling
$ 99.93
Alphacool - Eisball (RGB)
Type: Reservoir
Cooling
Alphacool - Fittings
Type: Custom Loop
Cooling
$ 81.10
Alphacool - NexXxoS ST30 Full Copper
Type: Custom Loop
Size (WxHxD): 360 mm (3 x 120 mm)
