In true overkill fashion I’ve put together this unnecessarily necessary beast of a system. Would love a 4090, 5090, or 7900 xtx but we all know GPUs are overpriced at the moment so here we are. This is also a departure from my previous builds that used a decent amount of RGB. Even though I feel like those didn’t use a ton of it, I’ve decided to add color in different ways. I might get some lighting just to illuminate the inside of the case, but that’s it. This is also a bit of a departure as it isn’t water cooled like my last ones. I might do a customer loop for the CPU soon, basically replacing the AIO with a single radiator loop to ramp the fans down a bit for a quieter build.

This will be used for gaming, streaming, video editing, and productivity…sometimes at the same time.


Specs

Case: Corsair 5000D AIRFLOW Tempered Glass Mid-Tower ATX PC Case — Black

Motherboard: Pro WS TRX50-SAGE WIFI
I managed to shoehorn a CEB motherboard into a case that doesn’t even have an E-ATX rating apparently. I can kinda see why as the cable pass-throughs on the top are almost fully covered, but the bottom ones aren’t due to the motherboard’s design. It works…it will work more once I get customer psu cables that should be more flexible than the ones that game with the Thermaltake PSU. I would say, whether you can fit this or an E-ATX motherboard in a 5000D will just depend on their design and your cable routing. If the side radiator is not being used then it should definitely fit.

CPU: AMD Ryzen™ Threadripper™ 7960X
Slight overclock to 5.6Ghz using PBO. I’m not looking to chase the sun here, just a little bump for single core workloads.

Graphics: Asus ProArt RTX 4070 Ti 12GB
Slight overclock +150mhz on core and memory.

Memory: 128GB G.SKILL Zeta R5 NEO DDR5 RAM (4x32GB)
6400MT/s
CL32-39-39-102

Storage:
- 2x 2TB Samsung 980 Pro nvme
- 4TB Samsung 990 Pro nvme
- 4TB SP Silicon Power 2.5” SSD

PSU: Thermaltake Toughpower GF3 1650W

Cooling:
- SilverStone XE360-TR5 360mm AIO
- 6x Noctua Noctua NF-A12x25 PWM Case Fans (intake)
- 4x Noctua NF-F12 iPPC 3000 PWM Fans (exhaust)

Monitors: 2x Dell S2722QC 27-inch 4K 60Hz

Keyboard: GMMK Pro
Lubed Glorious Panda Switches

Mice: Logitech MX Master 3S
