4000X custom loop

This is a case move, from the legendary Air Carbide 540, into a 4000x I got on sale. I decided to go with a custom loop with some EK parts with HydroX.

Was definitely time consuming, I definitely opted for soft tube as this is my first custom loop, in order to build a little confidence in what I was attempting here. Extremely tight fit as you can see. Hard line in the future for sure :)

Pump > GPU > 240(top) > CPU > 360(front) > back to pump.

Clear liquid was my choice to reduce risk of discoloration or gunking from dyes. Should my cooling system corrode, I’ll see a discoloration in the fluid through the lines.

Arguably, the 240 was unnecessary, because I’ve delidded the 10900k and running a modest 5ghz @ 1.275v, and have lowered my GPU voltage down as well to around 975mv while it’s running at 1975MhZ (1440p gaming). So the amount of electrical heat was negligible to add the 240, but I couldn’t help but throw it in there to make use of all the space.

Thanks for looking, appreciate the love!
Color(s): White
RGB Lighting? Yes
Theme: none
Cooling: Custom Liquid Cooling
Size: ATX
Type: General Build

Hardware

CPU
$ 515.00
Intel - Core i9-10900K
Socket: LGA 1200
Cores: 10
Motherboard
$ 179.95
ASUS - Rog Strix Gaming (Z590-A) (WiFi)
Chipset: Z590
CPU Socket: LGA 1200
Size: ATX
Memory
$ 325.00
Corsair - Vengeance Pro (3200MHz) (White/RGB)
Type: DDR4
Capacity: 32 GB
Graphics
$ 449.00
EVGA - GeForce FTW3 Ultra Gaming
Chip Manufacturer: NVIDIA
Chip: RTX 3070
Interface: PCIe x16
Storage
$ 69.00
Western Digital - WD Blue
Form Factor: M.2
Interface: M.2 (M)
Capacity: 250 GB
Storage
$ 102.22
Western Digital - WD Blue
Form Factor: 2.5 Inch
Interface: SATA 6 Gb/s
Capacity: 500 GB
Storage
$ 102.22
Western Digital - WD Blue (WDS100T2B0A)
Form Factor: 2.5 Inch
Interface: SATA 6 Gb/s
Capacity: 1 TB
PSU
$ 205.42
Corsair - RM850x (White)
Wattage: 850
Form Factor: ATX
Efficiency: 80+ Gold
Case
$ 134.99
Corsair - iCUE 4000X (White/RGB)
Type: Mid-Tower
Side Panel: Tempered Glass
RGB: Yes
Case Fan
$ 289.98
Corsair - LL120 (RGB) (White) (2x)
Size: 120 mm
Cooling
$ 249.00
Corsair - Hydro X XD5 (RGB)
Type: Pump/Reservoir Combo
Cooling
$ 72.99
Corsair - Hydro X XR5 (Slim)
Type: Radiator
Size (WxHxD): 360 mm
Cooling
$ 89.99
EKWB - CoolStream PE
Type: Custom Loop
Size (WxHxD): 240 mm (2 x 120 mm)
Cooling
$ 194.00
Accessories
$ 74.29
Estimated total value of this build:
$ 3,267.75
